Types of Siemens S5 PLC

There are many versions of the Siemens S5 PLC, all used for different purposes. They include:

• CPU 100

  This is the basic central processing unit of the S5-100 series. It is responsible for executing the control programs, processing inputs, and controlling outputs. The Siemens S5 PLC CPU 100 has different performance levels that range from simple to more complex.

• CPU 101

  This Siemens S5 PLC is designed for slightly more complex tasks than the CPU 100. It has more memory and faster processing speeds. It can handle more complex control programs and manage more input and output points.

• CPU 102

  These Siemens S5 PLCs are used in more advanced automation tasks. They boast even higher processing speeds and memory capacities than the CPUs 100 and 101. They are suitable for handling complex control strategies and large-scale automation projects.

• CPU 104

  The Siemens S5 PLC CPU 104 is used for high-performance control tasks. It has advanced features such as multitasking capabilities and extensive communication options.

• CPU 105

  These Siemens S5 PLCs are the most powerful control units in the S5-100 series. They have very high processing power and large memory capacities. The CPU 105 is designed to handle the most complex control tasks and the largest and most extensive automation systems.

• Rack and Power Supply

  The Siemens S5 PLCs are housed in racks. The number of slots in the racks varies depending on the size of the PLC. Besides housing the PLC, the rack also provides connections for the input and output modules. The Siemens S5 PLC also has a power supply unit that provides the necessary voltage and current for its operation.

Specifications and Maintenance of Siemens S5 PLC

• Environmental Conditions:

  Consider the environmental conditions where the S5 PLC will be installed. Factors such as temperature, humidity, dust, and electromagnetic interference should be taken into account to select a suitable hardware configuration and protective measures.

• Power Supply:

  Regularly check and maintain the power supply to ensure stable operation of the Siemens S5 PLC. Use an uninterruptible power supply (UPS) to protect against power fluctuations and outages.

• Backup and Documentation:

  Backup all programs, configurations, and data of the Siemens S5 PLC regularly. Keep documentation, including wiring diagrams, system configurations, and program listings, for easy reference and troubleshooting.

• System Configuration:

  Follow the guidelines for configuring the Siemens S5 PLC according to the specific requirements of the application. Set parameters such as input/output (I/O) configuration, communication settings, and program organization to optimize system performance.

• Regular Maintenance:

  Conduct regular inspections and maintenance of the Siemens S5 PLC hardware components. This includes cleaning, checking connections, and replacing worn-out parts.

• Training and Competence:

  Ensure that personnel operating and maintaining the Siemens S5 PLC are adequately trained and qualified. Provide training programs to enhance skills and knowledge in PLC programming, troubleshooting, and maintenance.

• Communication and Integration:

  Plan the communication and integration aspects of the Siemens S5 PLC with other devices and systems. Determine the required communication protocols, such as Profibus, MPI, or RS232, and configure them accordingly.

How to Choose Siemens S5 PLC

Picking the right Siemens S5 PLC for a specific task requires careful consideration of various factors:

• System Configuration

  Consider the size and complexity of the control system. For simple tasks, a smaller, less complex PLC may be sufficient. For larger systems with many inputs and outputs, a more powerful PLC will be needed.

• I/O Requirements

  Analyze the number and type of inputs and outputs needed for the application. Choose a PLC with sufficient I/O capacity and compatible I/O types (digital, analog, relay, etc.) to handle the signals.

• Processing Power

  The PLC's CPU should be powerful enough to handle the processing tasks and control logic requirements within the desired response time. For applications requiring complex calculations or fast control, a PLC with a more powerful CPU is necessary.

• Programming Capability

  Ensure that the PLC can be programmed using the required programming language (e.g., Ladder Logic, FBD, Structured Text) and that the programming tools are available and user-friendly. Consider the programming complexity and the programmer's familiarity with the tools.

• Communication Options

  Consider the necessary communication protocols and options for integrating the PLC with other devices, systems, or networks. Ensure that the selected PLC supports the required communication interfaces (e.g., Ethernet, Profibus, Serial).

• Environmental Conditions

  Consider the operating environment where the PLC will be installed. Factors such as temperature, humidity, dust, and exposure to chemicals or vibrations must be considered. Choose a PLC with appropriate enclosures and environmental ratings for the application.

• Future Expansion

  If there are plans for future system expansion or additional functionalities, consider selecting a PLC that allows for easy scalability and accommodates future growth.

• Cost

  Balance the project budget with the PLC's features, performance, and quality. While saving money is important, investing in a reliable and suitable PLC for long-term efficiency and effectiveness may be worthwhile.

• Vendor Support

  Consider the availability of technical support, training, and service from the PLC vendor or distributor. Reliable vendor support can significantly reduce downtime and help with troubleshooting and system maintenance.

By carefully evaluating these factors, selecting the appropriate Siemens S5 PLC for the specific application needs, ensuring efficient and reliable control, and implementing the desired automation goals, it will be possible.

How to DIY and Replace Siemens S5 PLC

As the Siemens S5 PLC is gradually phased out, there will be a need for a replacement. While it is advisable to have a trained technician from Siemens or a certified partner handle the replacement, here are some steps to make the change.

Before starting, make sure to have the following tools ready:

• Torx screwdriver
• Isolated screwdriver
• Small flat screwdriver
• 2 mm hex key
• 7 mm spanner
• cable stripper
• cutting pliers
• cable crimping tool
• torque screwdriver
• multimeter
• personal computer
• simatic s5 programming cable
• simatic s5 programming software

Here are some steps for a DIY approach to replacing Siemens S5 PLC.

• Power down the entire system and ensure that all electrical connections are safe.
• Carefully remove the existing Siemens S5 PLC unit using the Torx screwdriver.
• Open the terminal covers using the small flat screwdriver.
• Use the 7 mm spanner to remove the mounting screws, and with the 2 mm hex key, remove the screws holding the modules.
• Disconnect all the cables connected to the old PLC, including power, I/O, and communication cables.
• Install the new Siemens S7 PLC in the same position and manner as the old one.
• Connect all the cables to the new PLC, ensuring to double-check all connections to avoid errors.
• Use the torque screwdriver to connect all the terminals for digital inputs and outputs.
• Close the terminal covers using the small flat screwdriver.
• Power up the new PLC and test all functions to ensure that everything works as programmed.
• Dispose of the old PLC according to local regulations.

For any programming, wiring, or configuration, consult with the user manual or contact a certified Siemens partner for assistance.

Q&A

Q1. What is the Siemens S5 PLC?

A1. Siemens S5 PLC is a programmable logic controller used for industrial automation. It was designed by Siemens, a leading company in electrical engineering and electronics.

Q2. What is the function of Siemens S5 PLC?

A2. The Siemens S5 PLC is used for controlling and automating industrial processes. It is used in industries such as manufacturing, oil and gas, water treatment, and many others for tasks such as monitoring and controlling machine operations, process control, data acquisition and communication, and many other functions.

Q3. Is the Siemens S5 PLC still available?

A3. The Siemens S5 PLC is an older generation of PLCs and has been succeeded by the Siemens S7 PLC series. However, it is still used in many existing systems. Siemens provides limited support for legacy systems, but they recommend upgrading to a newer system for optimal performance and support.

Q4. What are the components of the Siemens S5 PLC?

A4. The Siemens S5 PLC has the following components: A power supply unit to provide the necessary power, an input unit to receive signals from input devices, an output unit to send signals to output devices, and a central processing unit (CPU) that processes the inputs and controls the outputs according to the user program. It also has a programming device used to create and edit the control program, and a communication processor (CP) for data exchange with other systems.

Q5. What programming languages are used in the Siemens S5 PLC?

A5. The Siemens S5 PLC is programmed using the STEP 5 programming language. This language uses ladder diagram (LD), function block diagram (FBD), and statement list (STL) programming languages.
