Micro motion coriolis mass flow meter

(1282 products available)

About micro motion coriolis mass flow meter

Types of Micro Motion Coriolis Mass Flow Meter

  • Single Tube Micro Motion Coriolis Mass Flow Meter

    This type of micro motion coriolis mass flow meter features just one flow tube. Here, the fluid moves inside the tube, and vibrations caused by an external force induce a coriolis effect. This is effective for measuring mass flow, density, temperature, and more, and is ideal for simple processes.

  • Duo-Bend Micro Motion Coriolis Mass Flow Meter

    This meter features two bends in its flow tube. The design leads to higher accuracy due to greater induced vibrations. It works best where high precision is needed, in low to moderate flow rates, and for fluids with varying density.

  • Inline Micro Motion Coriolis Mass Flow Meter

    This meter is integrated directly into process pipelines. It provides real-time data on mass flow, density, and more. It is used widely for basic QC in various industries. An inline sensor suits continuous monitoring and works well in stable environments.

  • High-Sensitivity Micro Motion Coriolis Mass Flow Meter

    This meter is designed to measure minute flow rates accurately. It is great for applications involving rare fluids or small quantities. It provides precise data where even slight changes matter, and users can depend on it for finely tuned processes.

  • Viscous Fluid Micro Motion Coriolis Mass Flow Meter

    This meter can handle fluids with thick or high-viscosity layers, such as slurries or oils. The flow tube's design accommodates such fluids without clogging, providing reliable measurements even under difficult conditions. It's ideal for users handling non-standard fluids.

  • Compact Micro Motion Coriolis Mass Flow Meter

    This micro motion coriolis mass flow meter is small and easy to install in tight spaces. It provides two-in-one measurement of mass flow and density. It is designed for users who need flowmeter sensors in limited physical areas.

Commercial Use Cases of Micro Motion Coriolis Mass Flow Meter

  • Chemical Processing

    It measures the mass flow, density, and composition of chemicals during mixing, reaction, and transfer processes. This ensures accurate material balance and prevents costly errors. With high precision, the meter improves product quality and consistency, leading to fewer reworks.

  • Oil and Gas Industry

    In this industry, it measures fluid flow rates in pipelines, helping to optimize extraction and transportation processes. The accuracy enables better resource management and reduced wastage. By providing precise data, it increases operational efficiency and reduces downtime from pipeline failures.

  • Food and Beverage Manufacturing

    In these industries, it measures the flow of liquids, gases, and slurries, providing critical data for quality control. It helps ensure consistent product formulations, improving food safety and taste. The accuracy reduces waste and rework, leading to cost savings for manufacturers.

  • Pharmaceutical Manufacturing

    In this space, it measures the flow of active ingredients and other solutions during drug production. This accuracy ensures proper dosages and consistent product quality. The high level of accuracy helps maintain compliance with regulations, avoiding fines while assuring safe and effective medications.

  • HVAC Systems

    It measures refrigerant flow in air conditioning and refrigeration systems, helping optimize heat exchange processes. This leads to improved energy efficiency and cooling performance. Better system performance leads to longer equipment life and reduced maintenance costs for users.

  • Aerospace and Defense

    It measures the flow of fuels and other fluids in various systems for its precision and reliability. It ensures proper fuel management in critical applications. It enhances safety by preventing fuel discrepancies, saving time on troubleshooting and emergency fixes.

What to Consider When Installing a Micro Motion Coriolis Mass Flow Meter

  • Optimal Orientation

    Since the meter can work in any position, it is mostly recommended that the meter tube be positioned horizontally for the most common fluids. This improves consistent mass flow and reliable readings. Certain applications may need a vertical or inclined setup, so consult the manufacturer's guidelines. Such installations usually happen in processes with thick suspensions or gases that need to be separated from liquids.

  • Minimal Vibrations

    Users should install the meter where there is little vibration from nearby equipment or piping. Excess vibrations can disrupt the sensitive coriolis readings, leading to inaccurate data. Mount the meter on vibration-dampening supports or in isolated areas to ensure stable operation.

  • Proper Pipe Configuration and length

    The flow meter works best when installed in straight pipeline sections. Make sure that there is adequate upstream and downstream piping so that the flow is stable. Usually, the ideal length upstream should equal at least ten pipe diameters, while the same length should be kept downstream.

  • Suitable Flow Conditions

    For best accuracy, the meter should operate within its specified flow range. Avoid installing it in conditions with high turbulence, low velocity, or significant pressure fluctuations. Monitor the flow conditions to keep them stable, which helps maintain consistent meter performance.

  • Proper Installation of Seals

    This is done to reinforce the integrity of the flow system. Incorrect installation leads to leakages, affecting safety, damaging equipment, and causing measurement errors. The users should install the meter according to the manufacturer's specifications for seal placement and selection rules so as to prevent leakages.

  • Correct Mounting

    Mount the meter securely to prevent movement yet ensure that it does not experience excessive rigidity. Such stiffness leads to mechanical damage and misalignment. Further, the user should also employ proper fasteners and supports that have, at most, minimal vibration transmission to mounting components.

Micro Motion Coriolis Mass Flow Meter Functionality and Design

  • Working Principle

    The micro motion coriolis mass flow meter works on the coriolis effect principle. As a fluid flows through the meter's tube, it vibrates in a specific manner. The angle of these vibrations changes based on the fluid's mass flow. The greater the flow, the larger the angle, which then translates into a mathematical measurement system for accurate mass flow determination. The other important aspect of the device is that it weighs the liquid flow traveling inside the tube, producing an extremely accurate density measurement.

  • Tube Design

    This is the part that carries the fluid. It directly impacts the flow and accuracy. The tube is usually made of stainless steel, featuring a smooth internal surface. This design prevents blockages in the flow and minimizes wear from the transported fluid.

  • Vibration Mechanism

    The external vibrations are generated by an actuator or piezoelectric element that creates a bending motion on the tube. The fluid's mass then induces coriolis forces. The resulting oscillations are measured and analyzed to determine flow rate.

  • Sensors and Signal Processing

    Accelerometers or position sensors detect the tube's vibrations. These sensors convert the mechanical motion into electrical signals. The corresponding signal variations are processed by an embedded micro motion mass flow meter processing unit that applies the coriolis equations to compute flow measurements.

  • Display and Output

    The processed data is then output for the users. Digital displays, interfaces, or communication protocols provide mass flow, density, and other data. Users can select display options to suit the real-time monitoring needs or further system integration.

How to Choose Micro Motion Coriolis Mass Flow Meter

  • Understanding Fluid Characteristics

    Fluid characteristics to consider when choosing an appropriate micro motion coriolis mass flow meter include the types of liquids, gases, or slurries to be measured, density, viscosity, and temperature. These considerations allow buyers to select a flow meter that suits the speed of the measured fluid so it doesn't get damaged while ensuring compatibility for efficient and optimal performance.

  • Accuracy and Precision Requirements

    Buyers should determine what accuracy and tolerance levels customers require in their flow measurement. This is because a meter may need to have a higher degree of accuracy in those industries where quality control or product safety is a priority, and this is where even tiny deviations matter.

  • Process Conditions

    The potential process pressure and temperature ranges that the flow meter will likely encounter should also be compatible with the flow meter material and design. This helps ensure that the meter functions properly under the target operating conditions. Buyers should also consider asking about the installation environment. Will it be a normal space or a hazardous area that requires special precautions? Other factors to consider include flow profile, pulsation, and transient.

  • Compliance and Certification

    Buyers should ensure the chosen meter complies with any industry regulations or standards since different industries have their unique rules. Further, it should be corrosive-resistant and come with certificates for hazardous areas if the fluid to be measured is flammable or explosive. All this helps ensure safety and legal adherence.

  • Vendor Expertise and Support

    When selecting the vendor, buyers need to ensure they have properly supported this flow meter. They have to be able to provide technical advice, installation support, and post-sales care. Choosing a vendor with a good reputation within the industry can ensure quality and reliable products.

  • Cost vs. Value

    Buyers have to balance the costs associated with the micro motion coriolis mass flow meter and the potential value it will deliver. So, while a highly accurate meter might be expensive, it could save more in the long run through improved efficiency and reduced waste in critical applications. On the flip side, for less-demanding environments, a more economical option may suffice that still offers decent performance.

Q&A

Q. What is the difference between the Coriolis and the volumetric flow meter?

The coriolis meter directly measures mass flow by sensing the change in vibrations induced by the fluid flow. Its main focus is on the fluid's actual mass, density, and composition. On the other hand, the volumetric flow meter calculates flow by measuring the fluid's volume passing through a specific point over time. It mainly focuses on the fluid's amount, not its density or mass.

Q. What are the most common features of a micro motion coriolis mass flow meter?

The most common features include the ability to measure multiple parameters, including mass flow, density, temperature, and viscosity, all through a single compact device. Further, they support diverse industrial applications by accurately handling various liquids, gases, and even dense slurries. Great news! They also come with a robust construction built to withstand extreme industrial environments and ensure longevity. They are, therefore, shielded against electromagnetic interference for reliable operation in critical spaces.

Q. Is installation of the micro motion coriolis mass flow meter easy?

Yes, the installation is quite easy, especially when compared to other flowmeters. This is because it does not require any straight piping runs or special positioning. However, ensuring proper alignment and minimizing vibrations around the meter's location are important for optimal accuracy.

Q. How can the micro motion coriolis mass flow meter be maintained?

As for maintenance, it is worth noting that the meter has no moving parts in the flow path. Hence, there is minimal wear on the device whatsoever. However, regular checks for leaks, vibration analysis around the area, and occasional cleaning of the flow tubes, if internal fouling is a possibility, will maintain further accuracy and extend the life of the product.
