Scribing calipers

Types of scribing calipers

Scribing calipers are precision tools used to transfer measurements accurately from one workpiece to another. They are widely used in woodworking, metalworking, and drafting tasks where exact measurements are crucial. There are two main types of scriber calipers: outside and inside:

• Outside Calipers:

  Outside calipers are commonly used in woodworking and metalworking to measure the outside dimensions of a workpiece. They have curved, pointed legs that can be adjusted to fit around the object's edges or corners. This allows the user to accurately transfer the measurement to another workpiece or marking tool, ensuring a precise fit or replication of the measurement. Outside calipers are particularly useful when measuring irregularly shaped objects or when a high degree of accuracy is required.

• Inside Calipers:

  Inside calipers, also known as dividers, are used to measure the internal dimensions of a workpiece, such as holes, grooves, or cavities. They have pointed legs that can be adjusted to fit inside the object's edges or corners. This allows the user to accurately transfer the measurement to another workpiece or marking tool. Inside calipers are particularly useful when measuring tight spaces or when a high degree of accuracy is required. They are often used in conjunction with outside calipers to ensure a precise fit between two or more workpieces.

Depending on the job requirements, scribing calipers may also have additional features, such as spring-loaded mechanisms for easy opening and closing, locking adjustments for holding measurements securely, and knurled knobs for better grip and control during use.

How to choose scribing calipers

Depending on the type of project, choosing the right scribing caliper is essential to ensure it meets the requirements. Here are some essential factors to consider;

• Adjustable vs. Fixed:

  There are two main types of calipers: adjustable and fixed. Adjustable can be changed to fit different measurements, while fixed is set to one measurement and used for marking it. Depending on the project needs, one may be preferred over the other.

• Material:

  Scribing calipers are typically made from metal or plastic. Metal ones tend to be more durable but can rust over time if not cared for properly. Plastic does not rust but may break more accessible than metal. Consider which material would be best for use over time.

• Point Style:

  The style of the points on the caliper will impact how precisely a measurement can be marked. Sharp points are more accurate than blunt ones, which may not create a visible mark. This is important when choosing a caliper for a specific project.

• Size:

  The size of the caliper will impact its portability and ease of use. Larger ones may be more challenging to carry around, while smaller ones may be easier but could lose some durability. Depending on where the caliper will be used, size is an essential factor.

• Budget:

  Calipers can range in price depending on the material, size, and brand. Consider how often it will need to be used to determine if a more expensive model is worth the investment or if a cheaper one will suffice. Budget is always an essential factor when making any purchase.

• Reviews:

  Before purchasing a caliper, it is always a good idea to read reviews from other customers. This can provide insight into how durable the product is over time, how easy it is to use, and if there are any issues that may arise that are not immediately visible. Reviews are always an essential part of any purchase.

How to use and product safety

Scribing calipers are handy tools for transferring measurements from one material to another accurately. It is essential to use them correctly for the best results.

• How to use

  First, the user should open the legs wide enough to accommodate the object being measured. Once measured, the distance is then locked by tightening the screw. The locked distance can then be transferred to the next object by simply opening the legs again and placing them over the next object. The process is repeated as many times as required to achieve a level of accuracy desired by the user.

  Calipers can also be used to scribe lines by simply placing the tool over the desired location and dragging it across the surface. It is important to note that scribing calipers can only achieve a level of accuracy of 0.5mm, which is sufficient for rough measurements but may not be ideal for precise measurements.

• Product safety

  When using scribing calipers, it is important to ensure that the legs are not opened too wide, as this can weaken their spring and affect their performance. Users should also be careful not to drop the tool, as this can cause it to bend or become damaged. In case the tool is dropped, it should be inspected to ensure it is still functioning properly and can still achieve the desired level of accuracy.

Functions, features, and design of scribing calipers

Scribing calipers are a go-to tool for accurately measuring and transferring distances in various workpieces. Their distinct features and design make them very effective in achieving precise results. Below are some of the key functions, features, and designs of scribing calipers:

Functions

• Measuring internal and external dimensions: Scribing calipers can be used to take measurements of internal and external dimensions of an object or workpiece. The two legs can be adjusted to the desired measurement and then transferred to a measuring scale or used to mark lines for cutting or machining.
• Marking circles and arcs: Scribing calipers can also be used to mark circles and arcs of any given diameter. By adjusting the two legs to the desired radius and a pivot point, the caliper can easily be used to mark the circle or arc with a pencil, ink, or any marking tool.

Features and design

• Legs: Scribing calipers come with two legs that are either pointed or scribed, which can be adjusted to the desired measurement. The pointed legs are used for marking on wood or metal, while the scribed legs are used for precise measurement and marking on paper or technical drawings.
• Adjustment nut: Scribing calipers feature an adjustment nut located on the hinge that locks the legs in place once the desired measurement is attained. It can be either a screw or a knob, depending on the model.
• Hinge: The hinge connects the two legs of the caliper and allows them to open and close. Some models have a locking mechanism that holds the legs in place once the desired measurement is attained.
• Scale: Some scribing calipers have a scale along one of its legs, indicating the measurement. This feature is helpful when precise measurements are required.
• Material: Scribing calipers are mainly made of durable materials such as stainless steel or brass for longevity and better performance. However, some models may have plastic components for lightweight construction.

Q&A

Q1: What are the differences between inside, outside, and depth scribing calipers?

A1: Inside calipers measure internal distances or dimensions, such as the inside diameter of a hole or opening. Outside calipers measure external distances or dimensions, like the outside diameter of a pipe or object. Depth calipers gauge the depth of holes, grooves, or recesses. Each type is optimized for accurately measuring its respective application area.

Q2: How to protect scriber calipers from rust?

A2: To protect metal calipers from rust, keep them in a dry location where humidity won’t affect them. Use the calipers regularly, as the oil from the skin can provide some protection if they are oiled. Apply a light coat of machine oil or WD-40 to the metal parts periodically. Consider using caliper covers or cases for added protection against moisture and debris.

Q3: How accurate are calipers?

A3: The accuracy of mechanical vernier calipers can be up to ±0.1mm. Digital calipers provide a higher level of accuracy, usually around ±0.02mm. The precise accuracy depends on the quality of the tool and the manufacturer’s specifications.

Q4: Can scriber calipers be used to measure length?

A4: No, scriber calipers cannot be used to measure length. They are designed to measure the distance between two points and dimensions accurately. On the other hand, vernier calipers can measure length, depth, internal, and external dimensions.
