Pipe rollers

Types of Pipe Rollers

Using pipe rollers can save time and effort, and they help ensure the quality and safety of pipe welding. There are different types of pipe rollers, such as As, Bs, Cs, Ds, which are effective for various situations.

• Adjustable Pipe Roller: An adjustable pipe roller can hold different pipe sizes. It has a support frame with movable roller arms. The movable roller arms can be shifted up and down to match the diameter of the pipe. This type of pipe roller is very versatile. It can be used for various pipe sizes without having to change the equipment.
• Automatic Pipe Roller: An automatic pipe roller is powered by an electric motor. It rotates the pipe during the welding process at a steady speed. This produces consistent welds. Some models also have speed control and different rotation directions to meet various needs. Using an automatic pipe roller can allow the welder's hands to be free to do other things while the pipe is turning.
• Beam Clamp Pipe Roller: A beam clamp pipe roller is designed to be used with an overhead beam. The beam clamp can be fastened securely to a structural beam using clamps and bolts. The pipe can then be connected to a movable roller on the other side. This allows heavy or long pipes suspended from a beam to be turned easily for welding. Using this type of roller makes it easier to weld pipes in situations where beams support the work.
• Chain Pipe Roller: A chain pipe roller uses a steel chain to secure the pipe in place while welding. The chain is operated manually or automatically, depending on the model. It can be used for different pipe sizes and shapes by adjusting the chain position. This type of roller works well for large or heavy pipes. It allows them to be secured firmly during the welding process.
• Fixed Pipe Roller: A fixed pipe roller supports the pipe at one or multiple locations. It can be made of different materials and shapes, such as U-shaped cups. The fixed roller is usually mounted at a comfortable height to do the welding work. This type of roller is often used to support pipes in a horizontal position. It can be used as a backstop while the pipe is being welded from one side.

Specifications and Maintenance of Pipe Rollers

Pipe roller supports are designed to hold up the weight of pipes while they are being welded. This means that they are generally made out of heavy gauge steel because they need to support large weights and assist operators in moving cumbersome pipes. They can be either fixed or adjustable in height between 2″ and 36″ on average, allowing them to cater to pipes of different dimensions. They can also be castor-mounted for greater ease of mobility during operations. Standard capacity weighs between 1,500 and 20,000 lbs but can go up to hundreds of thousands of pounds, depending on the specifications required.

The round roll surface of pipe rollers is manufactured to easily cradle pipes but can also be flat or V-shaped depending on the requirement. The surface is made out of different materials depending on manufacturer specifications and may be covered with rubber or polyurethane to prevent operations from scratching or damaging pipes while they are being welded. This also prevents pipes from slipping off the rollers while they are rolling. Other materials that the surface may be made of include phenolic, which is a resin compound, nylon plastic, or aluminum, to name a few, and are used for high-speed operations.

Maintenance of pipe rollers mainly consists of routine inspection and cleaning. Regular inspection is critical as it helps in the early detection of damages, which could be safety hazards. Pay close attention to check for loose, missing, or any warped parts. Roller bearings should be lubricated on a regular basis, and this can be done by any multipurpose lubricant. The entire unit should be cleaned regularly to prevent spillage or any other form of residue from accumulating and becoming a safety hazard.

Scenarios of pipe rollers

• Construction industry:

  In the construction industry, pipe rollers are commonly applied during the pipe installation on different types of surfaces. They help support the heavy weight of the pipes and keep them in position steady as well. This way, the installation becomes safer and easier for workers. Moreover, when adjustments are needed on the newly-installed pipes, the use of pipe rollers allows this to be done without much difficulty.

• Maintenance and repair:

  Pipe rollers find their application in the process of maintenance and repair as well. When it comes to the need for fixing or conducting routine check-ups on existing piping systems, these rollers also act as assists. They provide support to the pipes while allowing access from various angles for thorough examination or carrying out any necessary repairs more efficiently.

• Logistics and transportation:

  In the field of logistics and transportation, pipe rollers also play a very important role. Whether in warehouses or during the process of loading and unloading goods from trucks, containers, and so forth, they help make the handling of pipes easier and more efficient

How to choose pipe rollers

When choosing pipe rollers, several factors need to be considered to ensure that the roller tracks selected are suitable for the specific requirements and applications. Here are some key factors to consider when buying pipe rollers:

• Capacity and weight

  Determine the maximum weight the roller can handle and choose one with a capacity that meets or exceeds the weight of the pipes that will be used.

• Material

  Choose the pipe roller material based on compatibility with the pipe surface and the intended use environment.

• Size and dimensions

  Select pipe rollers that are the right size to support the pipes properly. Consider factors like the diameter and width of the roller.

• Design and configuration

  Choose the design of the roller (e.g., straight, V-shaped, etc.) based on the type of pipes being handled and the support needed.

• Mobility and transportation

  If mobility is important, consider the transportation of the rollers selected and how easily they can be moved to different locations.

• Cost

  Cost is an important consideration, but it should not be the only factor determining the final selection. Prioritize safety, quality, and suitability over cost.

Q&A

Q1: What materials do pipe rollers use to manufacture the frames and rollers?

A1: Different materials are used for frame and roller fabrication. Heavy-duty steel is usually the material for the frames, while carbon steel, nylon, PVC, and urethane are common materials used to make the rollers.

Q2: Which industries use pipe rollers?

A2: Pipe rollers are widely used in the plumbing, construction, oil and gas, manufacturing, and electrical industries.

Q3: What is the different carrying capacity of small and large pipe rollers?

A3: Small pipe rollers can handle pipes with diameters of between 1” and 4” (25 mm and 100 mm), and large rollers can accommodate pipes with diameters of between 6” and 12” (150 mm and 300 mm). The carrying capacity of individual models will vary, so it is always best to check the specifications of each roller.

Q4: Do pipe rollers help to orientate pipes as well as support them?

A4: Yes, Pipe rollers are designed not only to support pipes but also to allow for rotational movement of the pipes. This is especially useful in situations where the pipe requires maintenance or where access to the pipe is necessary.
