About electromagnetic braking system

Types of Electromagnetic Braking Systems

Of all the brakes, electromagnetic braking systems are the most diverse in type. This diversity is dependent on the suitability of the electromagnetic braking system to particular industries and applications. Out of all the kinds of these brakes, the most popular are the following electromagnetic brakes:

Electromagnetic Brake

Commonly found on lifts and other hoists, the electromagnetic brake functions by attracting its magnetic core with a solenoid when the coil is energized. This pulls the armature to the clutch plate to engage the motor, causing it to turn. When the power is off, a spring tension of the solenoid pulls the armature away from the clutch plate. This is what releases the motor. This braking system is often applied in low-powered & light motor equipment, especially hoist lifts.

Excitation Controlled

This is a far more complex machine since its brake works on the principle of reducing the excitation electric current of the generator to reduce the output of the generator. Its brake holds the rotor elements stationary while the field system experiences its magnetic flux variation.

Capacitive Magnetic Braking

Operating on the principle of a capacitor, the capacitive magnetic electromagnetic braking system sounds converts K.E. into electrical energy which in turn reduces the vehicle's speed. It is however important to state that this device works very efficiently at high speeds.

Active Control Electro-Mechanical Brakes

Characterized by the electric motor that controls the brake pad pressure, these brakes are used in metallic structures like towers, roofs, bridges, etc., where a change of pressure can cause these structures to fail.

Regenerative Brakes

These brakes return the absorbed energy back to the system. Mostly found in electric vehicles, it helps improve energy efficiency in these vehicles by as much as 70%.

Industrial Applications of an Electromagnetic Braking System

Mining

In mining, electromagnetic braking safety key words are used on generators for large mining trucks' propulsion, auxiliary brake systems, and underground mine electric vehicles, helping to dissipate energy gathering during mining operations.

Railways

In the railway industry, located in electric and commuter trains, railroad electromagnetic braking keywords provides braking resistance to electric trains' traction generators and resistors. The railway regen system is designed to redirect all the kinetic energy from the moving train back into the system as potent energy. Other areas this system is used on the rail infrastructure includes rail grid induction system, overhead wire and external DC track system power supply.

Marine

The electromagnetic braking generatorkeywords found on the rotating masses, including the marine propulsion and pumps, will stabilize and protect the ship and enable smooth energy absorption to prevent system damage and improve dynamic stability.

Utility

Useless large pumps, motors, fans, flywheels, и т.д., AC DC generators are all equipped with electromagnetic brakes, which help the machinery become more stable, absorbing excess energy and returning it to the driver system. This improves energy efficiency and reduces the likelihood of mechanical damage. Electromagnetic brakes are also used to equip generators for rugged off-road and high-horsepower engines.

Wind Power

In wind power, regeneration electromagnetic are embedded in wind turbine generators to support rotor mechanics and provide loads that help stabilize the wind turbine during low wind conditions and stopping.

Industrial Automation

These electromagnetic brakes are used on automated machines such as robots, conveyors, and other high-end technology, protecting delicate sensors, machines, and tools from possible damage, as well as improving energy efficiency. Em brakes restraint moving elements, including robot grippers, articulated arms, precision tools, and more, to prevent unwanted crashes and ensure ultra-precise controlled operations. In other automation areas like feeder vibrators and parts conveyors, em brakes help errors caused by part jams, misfeeds, and wrong orientations.

Transportation

Used on vehicles and other vulnerable transportation like ambulance, fire truck, and laptop carts, em brakes stabilize or hold devices during transport over bumpy roads. It also absorbs external forces like accidents resulting in less device damage and most importantly, quick delivery time in safer conditions.

Key Features of Electromagnetic Braking System

Smooth Operation

One of the main advantages of the electromagnetic braking system is that it doesn't require a direct physical contact. Because of this feature, there's no hit and hence a smooth operation, which doesn't hamper the braking mechanism.

Variability

Electromagnetic brakes can be controlled to vary the braking force exerted at any time. This makes these brakes an adjustable feature easy to integrate with other system components.

Quick Response

Electromagnetic brakes are commended for their ability to respond quickly to commands. This makes it possible for more braking power to be applied or withdrawn within a shorter time interval.

Durability

All electrical and electronic parts wear out sooner or later. What this means is an electromagnetic brake is almost wear-free because there is no direct contact between the two components. This is why all electromagnetic brakes' operational and maintenance costs have significantly less wear and tear.

Compact Design

As previously mentioned, the electromagnetic brake doesn't need direct contact, eliminating the need for complex mechanical linkages typical of other conventional brakes. This makes electromagnetic braking systems more compact and lightweight, hence easier to install in other tight spaces.

Automatic Release

Most electromagnetic brakes automatically release when there is no power supplied to them. For systems with redundant power, this feature is implemented that releases the brake when the power is off. These brakes are incredibly helpful to the emergency stop, automatic braking during vehicle descents, or securing equipment.

How to Choose an Electromagnetic Braking System

Brake Size

The brake size selected by a business owner will all depend on the client's load requirements and operating conditions. Buyers should ensure the brakes can adjust load variances and offer superior performance in overcoming the weights.

Heat Dissipation Capacity

As much as electromagnetic brakes are compact devices, they generate heat—a problem for limited space machines and vehicles. The heat dissipation capacity of these spaces must be considered before buying. Go for brakes with sufficient heat dissipation capacity.

Braking Time

Braking and acceleration time is another critical factor affecting the decision the Transportation industry considers. Buyers should choose brakes with braking times proportional to the client braking requirements.

Cyclic Operation

So far, electromagnetic brakes can operate continuously without much stress. However, the degree of cyclic operation greatly varied from one braking system to another. In other words, the ease of electromagnets varied with the frequency of operation. Buyers should consider brakes that suit their clients' operating frequency.

Power Consumption

While electromagnetic brakes usually have low power consumption, the consumption degree widely varies from one braking system to another. Buyers should get clients' power requirements. This will guide them in selecting the most suitable and power-efficient e-brake.

Q&A

Q1. What is the maintenance of electromagnetic brakes like for the typical?

A1. As previously mentioned, the electromagnetic brakes are wear-free, meaning they don't require much maintenance like the typical braking system. However, regular checks should be performed on the brake's electrical and electronic elements to ensure these elements operate efficiently.

Q2. Do electromagnetic brakes in vehicles come with redundancy?

A2. Yes, apart from vehicle brakes, almost all electromagnetic brakes come with redundancy features. Crediting this feature, the brakes can automatically release even when there's no power supply, making it useful during emergencies.

Q3. Are electromagnetic brakes eco-friendly?

A3. Yes, electromagnetic brakes are eco-friendly. The braking mechanism converts motion into electrical energy, which can be used to power the vehicle or other electrical equipment. This energy conversion helps consumption and makes these brakes environment-friendly.

Q4. What industries benefit from using electromagnetic brakes the most?

A4. The industries that benefit the most from these brakes are the engineering and automotive industries due to their energy efficiency, compactness, quick response, and low maintenance.

Q5: Why are electromagnetic brakes recommended for large vehicles?

A5: In large vehicles like trains and trucks, the electromagnetic automotive brakes provide braking resistance against large kinetic energy. They were specially designed to handle massive energy, thus making them ideal for large vehicles.
