YTL RS485 Communication China Digital Electricity Meter Token Electronic Energy Meters

No reviews yet
YTL RS485 Communication China Digital Electricity Meter Token Electronic Energy Meters
YTL RS485 Communication China Digital Electricity Meter Token Electronic Energy Meters
YTL RS485 Communication China Digital Electricity Meter Token Electronic Energy Meters
YTL RS485 Communication China Digital Electricity Meter Token Electronic Energy Meters
YTL RS485 Communication China Digital Electricity Meter Token Electronic Energy Meters
YTL RS485 Communication China Digital Electricity Meter Token Electronic Energy Meters

Key attributes

Industry-specific attributes

Phase
Single Phase
Measuring Energy Range
5(60)A
Output Voltage
110V/120V/220V/230V

Other attributes

Place of Origin
Zhejiang, China
Brand Name
YTL
Model Number
D116018
Display Type
Digital Only
Accuracy Class
1.0
Operating Temperature
-20~45℃
Dimensions
102.4*90*67.5mm
Standard work temperature
-20~45℃
Limit work temperature
-30~55℃
Relative humidity
≤85%
Power consumption
≤1W(when 220V 20A)
Creep
logical design of Anti-creep
Start current
0.4%Ib (class 1.0)
Model
D116018(energy meter)
Dimension
102.4*90*67.5mm
Impulse constant
800imp/kWh/1600imp/kWh
Display mode
LCD 5+2=99999,99 kWh

Packaging and delivery

Selling units
Single item
Single package size
9X7X7.2 cm
Single gross weight
1.000 kg

Lead time

Quantity (pieces) 1 - 1000 > 1000
Lead time (days) 45 To be negotiated
Still deciding? Get samples first! Order sample

Samples

Maximum order quantity: 1 piece
Sample price:
$99.00/piece

Customization options

Product descriptions from the supplier

Product Description
Specification
item
value
Place of Origin
China
Zhejiang
Brand Name
YTL
Model Number
D116018
Display Type
Digital Only
Phase
Single Phase
Measuring Energy Range
5(60)A
Accuracy Class
1.0
Output Voltage
110V/120V/220V/230V
Operating Temperature
-20~45℃
Dimensions
102.4*90*67.5mm
Standard work temperature
-20~45℃
Limit work temperature
-30~55℃
Relative humidity
≤85%
Power consumption
≤1W(when 220V 20A)
Creep
logical design of Anti-creep
Start current
0.4%Ib (class 1.0)
Model
D116018(energy meter)
Dimension
102.4*90*67.5mm
Impulse constant
800imp/kWh/1600imp/kWh
Display mode
LCD 5+2=99999,99 kWh
Packing & Delivery
white or color box, pallet for energy meter, single phase energy meter
Company Profile
Established in 1995, Zhejiang Yongtailong Electronic Co., Ltd. is located in the center of Shanghai, Hangzhou and Suzhou cities. As a professional manufacturer, YTL designs and produces electronic energy meters which are cost-efficient and ideal for the use in solutions for AMR/AMI at residential as well as industrial applications. YTL was one of the first companies in the domestic market with which had an internal R&D department as well as international sales business. Since our foundation in 1995 we have grown to a manufacturer which complies and meet to many specifications from our national and international partners. At present our export volume makes us a leading company for technology and product export to more than 50 countries throughout the world. YTL is devoted to develop and design all types of electronic energy meters, concentrators and solution applications. With a combined design of the special accessories, we have successfully developed series of competitive products of small size, multifunction, low power consumption and excellent performance. We offer a one-to-one service to our partners. With annually over 68 projects that are successfully finished and holding over 200 patents of design rights, we are also advanced in the technology and patents of current sampling.
FAQ
1. who are we?
We are based in Zhejiang, China, start from 2000,sell to Northern Europe(30.00%),Eastern Asia(20.00%),South Asia(10.00%),Eastern Europe(10.00%),Southeast Asia(6.00%),North America(5.00%),South America(5.00%),Mid East(5.00%),Southern Europe(5.00%),Central America(2.00%),Africa(1.00%),Oceania(1.00%). There are total about 301-500 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Three Phase Prepaid Meter,Single Phase STS Prepaid Meter,Three Phase Panel Meter,In Home Display,Single Phase DIN-Rail Meter With Relay

4. why should you buy from us not from other suppliers?
null

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW;
Accepted Payment Currency:USD,EUR;
Accepted Payment Type: T/T,L/C,Western Union,Cash;
Language Spoken:English,Chinese,Japanese
Customizable
500 - 999 pieces
$60.00
1000 - 4999 pieces
$50.00
>= 5000 pieces
$40.00
