Quantity (pieces) | 1 - 1000 | > 1000 |
Lead time (days) | 45 | To be negotiated |
item
|
value
|
Place of Origin
|
China
|
Zhejiang
|
|
Brand Name
|
YTL
|
Model Number
|
D116018
|
Display Type
|
Digital Only
|
Phase
|
Single Phase
|
Measuring Energy Range
|
5(60)A
|
Accuracy Class
|
1.0
|
Output Voltage
|
110V/120V/220V/230V
|
Operating Temperature
|
-20~45℃
|
Dimensions
|
102.4*90*67.5mm
|
Standard work temperature
|
-20~45℃
|
Limit work temperature
|
-30~55℃
|
Relative humidity
|
≤85%
|
Power consumption
|
≤1W(when 220V 20A)
|
Creep
|
logical design of Anti-creep
|
Start current
|
0.4%Ib (class 1.0)
|
Model
|
D116018(energy meter)
|
Dimension
|
102.4*90*67.5mm
|
Impulse constant
|
800imp/kWh/1600imp/kWh
|
Display mode
|
LCD 5+2=99999,99 kWh
|
